RJ18 rocker potentiometer

RJ18 rocker potentiometer

  • Series:RJ18
  • Format:See the following profile
  • Specifications

    Model: RJ18
    Name: Pan rocker potentiometer
    Main Specifications: Rated power: 0.0125W;
    Rated voltage: AC 50V / DC 5V;
    Partial pressure error: 44%-56%;
    Sliding stroke: 4mm;
    Sliding force: 110± 50 gf.
    Working temperature: -10°C ~ +55°C;
    Rotation life: more than 100,000 times;
    Features: The overall thickness is thin, the service life is high, and it can be moved in parallel in any direction of 360, and can be automatically reset.
    Applications: This product is mainly used in handheld pan/tilt, handheld triaxial stabilizers, game controllers, etc., mainly for direction control and mode switching.
    RJ18 rocker potentiometer product specifications

    First, MECHANICAL CHARACTERISTIC mechanical properties
    This product is currently mainly used in handheld pan/tilt, handheld triaxial stabilizers, game controllers, etc.
    Mainly used for direction control and mode switching.

    Second, ELECTRIC CHARACTERISTIC Electrical Characteristics
    1, Total resistance Total resistance: 10K± 20%
    2, Rated power rated power: 0.0125W
    3, Rated voltage rated voltage: AC 50V / DC 5V;
    4. Voltage divider error Partial pressure error: 44%-56%

    Three, ENDURANCE CHARACTERISTIC Durability characteristics
    1. Rotational life: 100,000 or more cycles Min

    Note:In this catalog,if some parame ters lr drawings are different from the "Approval sheet",it's subject to the "Approval sheet".

    Note: If the specifications and drawings of the manual and the acknowledgment are different, the acknowledgment shall prevail.

    Download RJ18 Rocker Potentiometer.pdf

    RJ18 Rocker Potentiometer Specification
