RG1102 ultra-thin 360 degree rotary potentiometer

RG1102 ultra-thin 360 degree rotary potentiometer

  • Series:RG1102
  • Format:See the following profile
  • Specifications

    model: RG1102
    name: Ultra-thin rotary potentiometer, 360-degree rotary potentiometer
    Main specifications: Rated power: 0.1W;
    Rotation angle: 360°;
    Electrically variable angle: 280°;
    Rotational torque: 0~30 gf.cm;
    Working temperature: -40 ° C to 85 ° C;
    Rotation life: 30,000 times;
    Features: The product is small in size, soft in rotation and through-shaft structure.
    Application areas: This product is currently mainly used in automotive dashboards, small household appliances, smart homes and other electronic devices.
    RG1102 ultra-thin 360 degree rotary potentiometer product specifications

    一、MECHANICAL CHARACTERISTIC
    1、 Effective electrical angle:280° ±5°
    2、Rotational Torque:0~30 gf.cm
    3、Push-Pull Strength of  Shaft :1kgf MAX
    4、Terminal strength:0.5kgf MAX

    二、ELECTRICAL CHARACTERISTIC
    1、Total resistance:47K±10%
    2、Rated power:0.1W

    三、ENDURANCE CHARACTERISTIC
    1、Rotational life:30,000 cycles Min

    Note:In this catalog,if some parame ters lr drawings are different from the "Approval sheet",it's subject to the "Approval sheet".



    下载RG1102超薄360度旋转电位器.pdf

    超薄360度旋转电位器规格书

           Guangdong Shengwei Electronic Products Co., Ltd. 27 years old resistance sensor manufacturer, specializing in the production of 360-degree rotary potentiometer, consult the ultra-thin 360-degree rotary potentiometer price to find Shengwei Electronics, manufacturers service hotline: 0769-38833333-881.
