| Potentiometer model: | RJ1605 series |
| name: |
RJ1605 Joystick Potentiometer |
| Main specifications: |
Dimensions: 16mm |
| Features: |
Smooth operation with high durability; Excellent offset precision; |
| Application areas: |
UAV's gaming controllers, toys and other related electronic devices. The main functions are UAV control, menu selection, etc. |
ONE、MECHANICAL CHARACTERISTIC
1. Lever Operating Force: 180±70 gf
2. Operating angle: 23° Max
TWO、ELECTRICAL CHARACTERISTIC
1. Rated power: 0.0125W
2. Maximum operating voltage: AC 50V DC 5V
3. Voltage divider error: 44%～56%
4. Insulation resistance: 100MΩ 1 Minute at DC 250V
5. Dielectric voltage: 1 Minute at AC 250V
THREE、ENDURANCE CHARACTERISTIC
1. Rotational life: 1,000,000 cycles Min
Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".
