EC08 Fexible Printed Circuit Encoder

EC08 Fexible Printed Circuit Encoder

  • Series:
  • Format:See the following profile
  • Specifications

    Encoder model: EC08 series
    name:

    EC08 Fexible Printed Circuit Encoder

    Main specifications:

    Rated voltage: DC 5V
    Number of detent: 0
    Pulses: 9P/360°
    Rotational torque: 5-40 gf.cm.
    Operating temperature: -20℃~85℃
    Rotational life: 30,000 cycles Min

    Features:

    Small size with large quantity (6PCS);

    FPC output.

    Application areas: Portable Rubik's Cube electronic toy products
    EC08 Encoder Product Specifications

    ONE、MECHANICAL CHARACTERISTIC
    1. Rotational Torque: 5~40gf.cm
    2. Total ratation angle: 360°
    3. Number of detent: 0

    TWO、ELECTRICAL CHARACTERISTIC
    1. Resolution: 9 Pulses
    2. Phase difference: ≥6ms
    3. Rated voltage: DC 5V
    4. Insulation Resistance: 50MΩ 1 Minute at DC 50V
    5. Dielectric Voltage: 1 Minute at AC 50V
    6. Chattering: ≤2ms
    7. Bounce: ≤2ms

    THREE、ENDURANCE CHARACTERISTIC
    1. Rotational Life: 30,000 cycles Min

    Note: In this catalog, if some parameters or drawings are different from the "Approvalsheet", it's subject to the "Approval sheet".

    download EC08.pdf
