MD47 Encoder Module with Touch Screen

MD47 Encoder Module with Touch Screen

  • Series:
  • Format:See the following profile
  • Specifications

    Module model: MD47 series
    name: MD47 Encoder Module with Touch Screen
    Main specifications:

    Dimensions: 47mm
    Number of detent: 30
    Press switch travel: 0.2~0.7mm
    Working temperature: -40℃~85℃
    Rotational life: 100,000 cycles Min

    Features:

    Stick to the touch screen for use;

    Function control via touch screen IC for easy operation;

    With a press switch conformation function.

    Application areas:

    Multimedia control, touch screen and other electronic devices.

    Mainly used for function switching and volume control.

    MD47 Product Specifications

    ONE、MECHANICAL CHARACTERISTIC
    Rotary section
    1. Rotational torque: 30±10mN.m
    2. Total ratational angle: 360°
    3. Number of detents: 30
    4. Rotational life: 100,000 cycles Min
    Switch Section
    1. Push switch travel: 0.2~0.7mm

    TWO、ELECTRICAL CHARACTERISTIC
    1. Insulation resistance: 100MΩ
    2. Dielectric voltage: 1 Minute at AC 300V
    3. Contact resistance: 200Ω Max

    Note: In this catalog, if some parameters or drawings are different from the "Approvalsheet", it's subject to the "Approval sheet".

    download MD47.pdf
